Safety Reachability Analysis for VTOL Vehicles

Reduced-Order VTOL Model · Backward Reachable Set · Simulink → helperOC Port

Abstract

A reduced-order VTOL model originally implemented as a Simulink demonstration was ported to the modern HJ reachability toolchain (helperOC on top of the level-set library) to compute backward reachable sets for transition-mode safety analysis. The deliverable is a recipe for taking a legacy Simulink stability study and turning it into a state-space envelope statement: "for any initial state in this set, no admissible disturbance can drive the vehicle outside the operating envelope inside the prediction horizon."

VTOL Reduced-Order Model

A planar longitudinal VTOL with state x = (u, w, q, θ) (forward and vertical body velocities, pitch rate, pitch angle) and input u_c = (T, δ_e) (thrust, elevator). The transition-mode dynamics linearise locally around a hover-to-cruise schedule:

ẋ    =  A(α) x  +  B(α) u_c  +  D d
α    ∈  [α_hover, α_cruise]
d    ∈  W
u_c  ∈  U

α follows the hover-to-cruise transition schedule, d is a bounded gust disturbance, u_c respects thrust and elevator limits. Operating envelope: O = { x : φ_min ≤ θ ≤ φ_max, u ≥ u_min } (avoid stall at low forward speed and avoid pitch-up beyond stability margin).

Backward Reachable Set under Worst-Case Disturbance

Compute the set of initial states from which the controller can keep the VTOL inside O for the full prediction horizon, against the worst-case admissible disturbance. The HJI value function:

∂V/∂t + min_{u_c ∈ U} max_{d ∈ W} ⟨f(x, u_c, d), ∇V⟩ = 0
V(x, T)  =  L(x)

L(x) is the signed distance to the envelope boundary ∂O.

The zero-superlevel set { x : V(x, 0) ≥ 0 } is the safe BRS: any state in it admits a control schedule that keeps x(t) ∈ O for all t ∈ [0, T], regardless of the gust profile in W. helperOC handles the min-max Hamiltonian directly; the Simulink-only legacy version could only check stability locally, not envelope-wide.

Simulation Output

Closed-loop transition between hover and forward flight under HJR-derived envelope constraints. The first clip is a baseline trajectory inside the BRS; the second crosses the BRS boundary at a heavily disturbed initial condition and triggers the safety override.

Reduced-order VTOL transition simulation showing pitch and forward speed evolution inside the safe backward reachable set

Baseline transition (x(0) ∈ BRS)

Reduced-order VTOL with the safety override engaged after a disturbance pushes the state toward the envelope boundary

Disturbed transition · safety override active

Why this matters

The legacy Simulink workflow could verify a single nominal trajectory was stable. The HJR port answers a strictly stronger question: which set of initial conditions admit any safe trajectory under any admissible disturbance? That is the difference between "this controller doesn't fall over on the demo" and "this controller has a certified envelope of operation," which is the language that flight-test engineers use when they write release-to-flight cases.
